Arena
Pixel Pitch:
Pitch: 2.9mm, 3.9mm,4.8mm
Pitch: 6.25mm, 7.8mm, 10.4mm
Brightness:
Standard: 4000-4500 nits
High brightness: 6000-6500 nits
Ultra brightness: 9000-10,000 nits
Visual:
Standard refresh rate: 1920Hz
High refrsesh rate: 3840Hz
Grayscale: 16 bits
Mechanical:
Standard panel size: 1000×1000 mm
Customized panel size: 500x1000mm
Customized panel size: 1500x1000mm
LED module size: 250x500mm
Aluminum profile extruded panel frame
IP65 protection:
Full sealed aluminum module
chassis with rubber
Water proof connectors (between modules)
Drain hole is designed at the bottom of the panel avoid ponding
High standard of Waterproofing
Optimized heat sinking:
Panel size: 250x1000mm
Panel size: 250mmx750mm
Panel size: 500x250mm
Panel size: 250x250mm
Direct pin connection:
No cabling design between the LED module & panel
Direct-Pin design to guarantee the stable connection of power & signal, extremely low failure rate, more adaptable to long-term extreme application environment.
Modular mechanical design:
LED module & power box can be easily take out from the front & back, easy replacement of brocken parts
100% full front service available, direct wall mounted
Nature cooling design for extreme allication enviroment
Optimized heat sinking design
Customized panel size:
Standard panel size: 1000×1000 mm
Customized panel size: 500x1000mm
Customized panel size: 1500x1000mm
LED module size: 250x500mm
90 right angle corner:
Seamless 90 degree right angle corner,
Perfect fit into the building structure
Perfect solution for the 3D naked eye LED display
