Mythic COB
Pixel Pitch:
Flip-Chip COB LED Display
Pitch: 0.6mm, 0.78mm,0.9mm
Pitch: 1.2mm, 1.5mm, 1.8mm
Brightness:
Standard: 600 nits
High brightness: 1000 nits
Ultra brightness: 2000 nits
Visual:
Standard refresh rate: 1920Hz
High refrsesh rate: 3840Hz
Grayscale: 16 bits
Mechanical:
Panel size: 600×337.5mm
LED module size: 150×168.75mm
Aluminum die-casting frame, 4kg
Superior visual quality:
COB Technology brings a smaller pixel pitch and higher pixel density will reduce the viewing distance.
This means that viewers will be able to stand close to a display and still view it comfortably without noticing the individual pixels.
Perfect grayscale:
The contrast is the ratio of the brightness of the LED display at its whitest and darkest. Achieves a color contrast ratio of up to 10,000:1, ensuring vibrant, clear visuals. Capture the little details even in low light. Adopting black coating technology, nonreflective surface and supreme black uniformity help to display true-to-life images.
16:9 Aspect ratio:
The 16:9 aspect ratio is the standard for many devices, including: TVs, Computer monitors, Mobile devices, LED display trailers, and Digital video cameras
It’s also the universal standard image format for 1080p, 2160p, and 4320p formats.
The 16:9 aspect ratio is ideal for displaying action sequences and panoramic scenes because it provides a wide view. It’s also compatible with most standard HD televisions and monitors.
Flip Chip technology:
The flip chip COB packaging technology, combined with a common cathode circuit design, enhances display effects while saving 40% energy than conventional LED screens
Color calibration:
Color calibration is the process of ensuring consistency of color on all LED modules on a display.
Color calibration ensures that there is no moire, all colors are at a uniform temperature and a balanced white colour.
LED screen calibration is critical for all LED displays. A well calibrated led screen provides an engaging visually pleasing experience for the viewers
Direct wall mounted:
100% full front mainteanance
LED modules are magnetic front service, the panel frame can be directed mounted on the wall/plywood with screws.
Frame bars for positioning & installation are included.
