Impact
Pixel Pitch:
Indoor: 1.5mm, 1.9mm, 2.6mm
Brightness:
Standard: 600 nits
High brightness: 1000 nits
Application:
Event
Tradeshow
Church LED
TV Studio
Mechanical:
LED module size: 250x250mm
Panel size: 500x500mm
Aluminum die-casting
Concave & convex available
DCI-P3,7680Hz, 16 bits:
DCI-P3,7680Hz,16 bits
With the xR version for LEDs works in camera. 98% match DCI-P3. Up to 7680Hz super high refresh rate 16 bits grayscale
R500 is specialized designed for rental applications needs minimum pixel pitches for applications of HD, 4K, XR, virtual production.
R500 is also a LED panel works properly for camera.
Perfect grayscale:
R500 Series diode board design is base on the require of high grayscale.
The breadth of grayscale levels a screen can display correlates to its ability to render bright colors accurately and depict images with enhanced depth and clarity.
Light weight & compact:
Die-casting aluminum LED panel
Smart mechanical design, easy for installation and packing
Modular design:
Magnetic front service design for the LED modules
LED module can be easily take out from the front and back, user-friendly locking system
Corner protection:
The foldable corner protectors are located around the corners of the panels which help to welly prevent the shocks durting installation and transportation.
Flexible curve:
Thanks to the fast curve lockingsystem, it is easily to form 5–12 degrees concave and convex installation to get a seamless curve surface for the LED display.
Available with Brompton:
Specialized used for xR, virtual production
Compatible with Brompton system, as well as Novastar & Colorlight
